Product description:
1. high power 1350W imported heating components are used to reduce the heating time by several times, and the heating can be completed in 20 seconds;
2. the smoke pipe adopts 316 stainless steel Ba seamless pipe technology with coarser outer diameter. The high durability pipe surface is smooth and not easy to remain. The latest brazing technology is adopted to make the thermal response faster and the temperature more stable.
3. electronic constant temperature technology is adopted, which will not cause odor due to out of control temperature. 100% smoke oil is completely burned, and it is very dry and low temperature, which is more environmentally friendly and healthy.
4. the air pump with air filtration is adopted to make the air entering the smoke pipe more pure and reduce the risk of accelerated blockage of dust mixed with mist and oil in the air;
5. Taiwan backward blade high-speed fan is adopted, so there is no need to consider the problems such as cleaning and blocking of air outlet filter cotton.
6. the new oil pump control technology enables the machine to smoothly and continuously output smoke even at the minimum amount of smoke;
7. support wireless remote control, with stronger adaptability;
8. multiple safety monitoring modes, different component damage displays different fault codes, making maintenance more convenient and fast; In addition to the electronic temperature control heater, mechanical temperature protection is added to prevent the continuous high-temperature heating caused by the damage of the main board; It is safer to use and easier to maintain.
9. the structure of the whole machine is reasonably designed to completely isolate the circuit from the air path, and there is no need to worry about the occurrence of leakage, short circuit, out of control and other faults caused by long-term condensation of mist oil on the circuit board;
10. built in multi-functional operation control; There are built-in time control, manual smoke control and continuous smoke control;
11. the original automatic cleaning mode, which can be manually or remotely controlled by DMX512, makes the maintenance more convenient;
12. the electronic oil-free protection design is adopted. When the machine detects that there is no oil, the machine automatically enters the protection state to prevent damage caused by long-time dry pumping of the oil pump. After adding mist oil, it is not necessary to restart or operate the machine. The protection function can be quickly and remotely removed through DMX512 (the menu can be closed);
13. the unique theater mode can automatically turn off the air pump and standby wind speed 60 seconds after stopping smoking, so as to reduce the noise (the menu can choose to turn off);
14. digital liquid crystal display is adopted, which is more powerful, simpler, more convenient and more humanized;
15. DMX-512 signal control, 3 channels in total;
16. the environment-friendly disposable oil drum design greatly reduces the pollution of mist oil.
Technical parameter:
Model | MAGICPLUS MP-1500II |
Voltage | AC 220V-240V 50/60Hz |
Current limiting protection | AC 250V/10A |
Power | 1500W |
Preheating time | 20 seconds |
Smoke output | 15000cuft/min |
Maximum continuous smoking time | Always |
Maximum working time | 100% smoke volume, maximum working time up to 7 hours |
Control mode | DMX 512、remote control choose、LED Panel Control |
DMX channel | 3 |
Tank volume | 4L |
Weight | |
Machine dimensions |
